Dayton 3K613 Split-Phase Belt Drive Motor, 1/6 Hp, 48 Frame, 115/208-230V Ac

USD 278.99 USD

SKU: y8KiEHDD

Brand: DAYTON

MPN: 3K613

GTIN: 190735290255

Condition: New

Tags: 1.6 1/2" 115/208-230 14.5000 15.320 1701-1800 1725 190735290255 3.6/1.7-1.8 3K613 40 Degrees C 5-5/8" 6-15/16" 8-7/16" 8.250 AUTO Ball Belt Dr Fan/Blower Belt Drive Motor Continuous Cradle CW/CCW DAYTON K613 Open Dripproof Rolled Steel Split-Phase

Categories: Heavy Equipment, Parts & Attachments

Specifications

Brand	DAYTON
Model	3K613
MPN	3K613
Style	Belt Drive Motor
Item	Belt Drive Motor
Overall Length	8-7/16"
Type	Belt Drive Motor
Weight	14.5000
Length	15.320
Mounting	Cradle
Width	8.250
Depth	8.250
Voltage	115/208-230
Bearings	Ball
Frame Material	Rolled Steel
Duty	Continuous
HP	1/6
Full Load Amps	3.6/1.7-1.8
Motor Type	Split-Phase
Thermal Protection	Auto
Max. Ambient Temp.	40 Degrees C
RPM Range	1701-1800
Shaft Dia. (In.)	1/2
Length Less Shaft	6-15/16"
Nameplate RPM	1725
Rotation	CW/CCW
Enclosure	Open Dripproof
Motor Sub Application	Belt Dr Fan/Blower
Body Dia.	5-5/8"
UPC	190735290255
